KOMBO

OPTICAL SYSTEM

Lifetime: 50 000 h (L-70)
Light source: LT-Design LED module, Osram chips
Ledil optics
Front board made of tempered transparent glass

STRUCTURE

Cooling, passive
Aluminium body, high-pressure moulding
Body, polymer, injected
CE Qualification
Easy to assemble
Protection: IP65
In coulours of the RAL range of colours

DOWNLOADS

▼ 300763 Installation guide
▼ 300763 Datasheet

APPLICATION

External
Parking spaces
Pedestrian precincts
Motorways
Bike paths
parks
Industrial areas

OPTIONS

1-10V Regulation
DALI

VARIANTS

Ordering Code Light Output
[lm]		 CRI System Power
[W]		 Color Temperature
[K]		 Beam Angle Dimming Dimensions
[mm]		 Warranty
[year]		 Eulumdat
300763 2467 >70 14.98 3500 120° - 290x673x119 5 ▼
300764 4093 >70 23.99 3500 120° - 290x673x119 5 ▼
300778 6094 >70 37.68 3500 120° - 290x673x119 5 ▼
300779 9163 >70 56.55 3500 120° - 290x673x119 5 ▼
301017 12139 >70 74.62 3500 120° - 290x673x119 5 ▼
301028 14267 >70 95.12 3500 120° - 290x673x119 5 ▼
